CK450HFE

Saving Time While Handling Large Volumes

CK450HFE is one of the most popular machines in our entire range.

Download Brochure
Focus Enviro | Specialists in material processing equipment
Focus Enviro | Specialists in material processing equipment

Introducing

The CK450HFE can be found in logistic centres, warehouses and large retail shops with substantial volumes of waste.

The Full Eject System (HFE) ensures fast operation, allows switching between different waste streams and avoids contamination.

The CK450HFE is an ideal paper compactor, with it’s height making it perfect for hand-feeding and very suitable for dock level loading. It is also a very suitable compactor for cardboard and soft plastics. The wide filling chamber is ideal for use with bin tipping equipment. The vertical tie orientation ensures bale integrity for certain materials.

VIEW GALLERY

Key Highlights

Quick design feature overview

Specification

CK450HFE

  • 4 x Steel Wires, Black Annealed
  • Bale Ejection System
  • Tying Direction
  • 3.5mm dia., 4.6m long
  • Full Eject
  • Vertical

Baler Dimensions

  • Height (mm)
  • Width (mm)
  • Length (mm)
  • Weight
  • Feed Opening (L x W)
  • 2430mm (to top of standard hopper)
  • 1780
  • 6250
  • Approx. 5500kg
  • 1400 x 1040mm

Baler Performance

  • Compaction Force
  • Cycle Time
  • Motor
  • Power Supply
  • Noise Level
  • 50 tonnes
  • 86 sec / 60 sec / 42 sec
  • 7.5kW / 11kW / 15kW
  • 3 x 415V, 50Hz
  • 80dBA

Bale Dimensions

  • Height (mm)
  • Width (mm)
  • Length (mm)
  • Bale Weight Cardboard (approx)
  • Bale Weight Plastic (approx)
  • 750
  • 1150
  • 950 - 1200mm
  • Up to 450kg
  • Up to 500kg
